Technical Specification:
| Suitable paper | One & Two side PE coated paper, glossy coated paper.Paper weight:250~350 qsm |
| Lid size | Lid height:8~15 mmDiameter40~100mm&100~145mm |
| Speed | 80-110pcs/minute |
| Power Source | AC380V 3-phase,50Hz |
| Total power | 1OKW |
| Air requirement | Consumption0.3 cubic meter/minute,Pressure:0.4MPa |
| Machine size | 2700X1650X2000mm |
| Weight | 2100KG |
Advantage:
l Patent equipment, high speed. lFeed roll paper, l Auto creasing(guide line), lAuto emboss (logo and shape on lid top, also make cross cut), lAuto punching(cut roll paper to lid disc), l Lid made by one paper disc, save cost. l PLC control + servo motor feed paper lOpen cam + shaft + cam + gear control movement, stable and reliable
